<Grid>
        <Image
            x:Name="displayImage" />
        <Canvas
            x:Name="displayCanvas" />
    </Grid>

namespace WpfApplication30
{
  using System.Windows;
  using System.Windows.Media.Imaging;

  public partial class MainWindow : Window
  {
    public MainWindow()
    {
      InitializeComponent();
      this.Loaded += OnLoaded;
    }
    void OnLoaded(object sender, RoutedEventArgs e)
    {
      // The FrameRenderInfo is a class I've written which does 2 things for me
      // 1) Provides methods to 'copy/capture' per-frame data.
      // 2) Provides methods to render that data to a canvas.
      // Hence, we construct it with our canvas.
      this.frameRenderInfo = new FrameRenderInfo(this.displayCanvas);

      // Standard - create the RealSense SenseManager, main object for talking
      // to the camera 'pipeline'
      this.senseManager = PXCMSenseManager.CreateInstance();

      // Ask it to switch on person tracking.
      var status = this.senseManager.EnablePersonTracking();

      if (status == pxcmStatus.PXCM_STATUS_NO_ERROR)
      {
        this.personModule = this.senseManager.QueryPersonTracking();

        // Configure person tracking to suit our needs.
        this.ConfigureModules();

        // Initialise the sense manager giving it a callback to call
        // when it has frames of data for us.
        status = this.senseManager.Init(
          new PXCMSenseManager.Handler()
          {
            onModuleProcessedFrame = OnModuleProcessedFrameThreadPool
          }
        );

        if (status == pxcmStatus.PXCM_STATUS_NO_ERROR)
        {
          // Mirror so that L<->R are reversed.
          this.senseManager.captureManager.device.SetMirrorMode(
            PXCMCapture.Device.MirrorMode.MIRROR_MODE_HORIZONTAL);

          // Tell it to throw frames at us as soon as it has some via
          // our callback.
          this.senseManager.StreamFrames(false);
        }
      }
    }
    void ConfigureModules()
    {
      using (var config = this.personModule.QueryConfiguration())
      {
        // We ask for a maximum of one person.
        var tracking = config.QueryTracking();
        tracking.SetMaxTrackedPersons(1);
        tracking.Enable();

        // We ask for a maximum of 1 person and we ask for full body tracking although
        // I've yet to see that deliver anything that's not in the upper body.
        var skeleton = config.QuerySkeletonJoints();
        skeleton.SetMaxTrackedPersons(1);
        skeleton.SetTrackingArea(
          PXCMPersonTrackingConfiguration.SkeletonJointsConfiguration.SkeletonMode.AREA_FULL_BODY);
        skeleton.Enable();
      }
    }
    /// <summary>
    /// Handler for each frame, runs on some thread that I don't own and so I have to
    /// copy data from the frame, store it for later when we can render it from the
    /// UI thread.
    /// </summary>
    /// <param name="mid"></param>
    /// <param name="module"></param>
    /// <param name="sample"></param>
    /// <returns></returns>
    pxcmStatus OnModuleProcessedFrameThreadPool(int mid, PXCMBase module, PXCMCapture.Sample sample)
    {
      // We check to see if our 'buffer' is busy. If so, we drop the frame and carry on.
      if (this.frameRenderInfo.Acquire())
      {
        // Copy the data for the color video frame.
        this.frameRenderInfo.CaptureColorImage(sample);

        // Do we have data from the person tracking module? Hopefully...
        if (mid == PXCMPersonTrackingModule.CUID)
        {
          using (var data = this.personModule.QueryOutput())
          {
            // Copy the bounding boxes around the torso and the head.
            this.frameRenderInfo.CapturePersonData(data);

            // Copy any individual joints that we can find.
            this.frameRenderInfo.CaptureJointData(data);
          }
        }
        // Now, switch to the UI thread to draw what we have captured.
        this.Dispatcher.Invoke(this.RenderOnUIThread);
      }
      return (pxcmStatus.PXCM_STATUS_NO_ERROR);
    }
    /// <summary>
    /// Draws the data that was previously captured.
    /// </summary>
    void RenderOnUIThread()
    {
      // Create our bitmap if we haven't already - need to do this here because
      // it needs to be done on the UI thread and it can't be done before we
      // have the sizes from the video frames.
      this.InitialiseColorFrameBitmap();

      // Update with the latest video frame.
      this.frameRenderInfo.RenderBitmap(this.colorFrameBitmap);

      // Draw boxes for the head and torso.
      this.frameRenderInfo.RenderPersonData();

      // Draw ellipses for any joints we know about.
      this.frameRenderInfo.RenderJointData();

      // Allow our 'buffer' to pick up the next lot of data (we may have
      // missed frames in the meantime).
      this.frameRenderInfo.Release();
    }
    /// <summary>
    /// Creates the WriteableBitmap that we use for displaying frames
    /// from the colour source.
    /// </summary>
    void InitialiseColorFrameBitmap()
    {
      if (this.colorFrameBitmap == null)
      {
        this.colorFrameBitmap = this.frameRenderInfo.CreateBitmap();
        this.displayImage.Source = this.colorFrameBitmap;
      }
    }
    FrameRenderInfo frameRenderInfo;
    WriteableBitmap colorFrameBitmap;
    PXCMPersonTrackingModule personModule;
    PXCMSenseManager senseManager;
  }
}

namespace WpfApplication30
{
  using System;
  using System.Collections.Generic;
  using System.Linq;
  using System.Threading;
  using System.Windows;
  using System.Windows.Controls;
  using System.Windows.Media;
  using System.Windows.Media.Imaging;
  using System.Windows.Shapes;
  using static PXCMPersonTrackingData.PersonJoints;
  class FrameRenderInfo
  {
    internal FrameRenderInfo(Canvas canvas)
    {
      this.canvas = canvas;
      this.jointEllipses = new Dictionary<JointType, Ellipse>();
      this.whiteBrush = new SolidColorBrush(Colors.White);
    }
    /// <summary>
    /// Attempts! to ensure that we are either handling a frame or
    /// rendering a frame but not both at the same time.
    /// </summary>
    /// <returns></returns>
    internal bool Acquire()
    {
      return (Interlocked.CompareExchange(ref this.busyFlag, 1, 0) == 0);
    }
    /// <summary>
    /// Companion to Acquire
    /// </summary>
    internal void Release()
    {
      Interlocked.Decrement(ref this.busyFlag);
    }
    /// <summary>
    /// Copies the data from the current colour frame off the video source
    /// into a buffer so that we can later render it. Also picks up the
    /// dimensions of that frame on first use.
    /// </summary>
    /// <param name="sample"></param>
    internal void CaptureColorImage(PXCMCapture.Sample sample)
    {
      PXCMImage.ImageData colorImage;

      if (sample.color.AcquireAccess(
          PXCMImage.Access.ACCESS_READ,
          PXCMImage.PixelFormat.PIXEL_FORMAT_RGB32,
          out colorImage) == pxcmStatus.PXCM_STATUS_NO_ERROR)
      {
        if (!this.colorFrameDimensions.HasArea)
        {
          this.colorFrameDimensions.Width = sample.color.info.width;
          this.colorFrameDimensions.Height = sample.color.info.height;
          this.xScaleMultiplierCameraToCanvas = 1.0d / this.colorFrameDimensions.Width;
          this.yScaleMultiplierCameraToCanvas = 1.0d / this.colorFrameDimensions.Height;
        }

        if (this.colorFrameBuffer == null)
        {
          this.colorFrameBuffer = new byte[
            this.colorFrameDimensions.Width * this.colorFrameDimensions.Height * 4];
        }
        colorImage.ToByteArray(0, this.colorFrameBuffer);

        sample.color.ReleaseAccess(colorImage);
      }
    }
    /// <summary>
    /// Captures the bounding boxes around the head and torso for later rendering.
    /// </summary>
    /// <param name="data"></param>
    internal void CapturePersonData(PXCMPersonTrackingData data)
    {
      this.headBox.w = this.bodyBox.w = 0;
      this.headBox.h = this.bodyBox.h = 0;

      if (data.QueryNumberOfPeople() > 0)
      {
        var personData = data.QueryPersonData(
          PXCMPersonTrackingData.AccessOrderType.ACCESS_ORDER_BY_ID, 0);

        if (personData != null)
        {
          this.CaptureHeadAndBodyBoxes(personData);
        }
      }
    }
    /// <summary>
    /// Does the work of capturing the head and torso bounding boxes.
    /// </summary>
    /// <param name="person"></param>
    void CaptureHeadAndBodyBoxes(PXCMPersonTrackingData.Person person)
    {
      var tracking = person.QueryTracking();

      var boundingBox = tracking?.Query2DBoundingBox();

      if ((boundingBox != null) &&
        (boundingBox.confidence > 50))
      {
        this.bodyBox = boundingBox.rect;
      }
      boundingBox = tracking?.QueryHeadBoundingBox();

      if ((boundingBox != null) &&
        (boundingBox.confidence > 50))
      {
        this.headBox = boundingBox.rect;
      }
    }
    /// <summary>
    /// Captures the skeletal joints - unsure exactly about the role here of StartTracking()
    /// but it seems to be needed to get the joints.
    /// </summary>
    /// <param name="data"></param>
    internal void CaptureJointData(PXCMPersonTrackingData data)
    {
      this.currentJoints = null;

      if (data.QueryNumberOfPeople() > 0)
      {
        if (data.GetTrackingState() == PXCMPersonTrackingData.TrackingState.TRACKING_STATE_DETECTING)
        {
          data.StartTracking(0);
        }
        else
        {
          var personData = data.QueryPersonData(
            PXCMPersonTrackingData.AccessOrderType.ACCESS_ORDER_BY_ID, 0);

          var joints = personData?.QuerySkeletonJoints();
          var jointCount = joints?.QueryNumJoints();

          if (jointCount > 0)
          {
            if (!joints.QueryJoints(out this.currentJoints))
            {
              this.currentJoints = null;
            }
          }
        }
      }
    }

    /// <summary>
    /// Renders the head and torso boxes to the Canvas by scaling them and
    /// controlling their visibility.
    /// </summary>
    internal void RenderPersonData()
    {
      if (this.headRectangle == null)
      {
        this.headRectangle = this.MakeRectangle(Colors.Red);
        this.bodyRectangle = this.MakeRectangle(Colors.Green);
      }
      this.PositionCanvasShapeForBoundingBox(this.headRectangle,
        this.headBox.x, this.headBox.y, this.headBox.w, this.headBox.h);
      this.PositionCanvasShapeForBoundingBox(this.bodyRectangle,
        this.bodyBox.x, this.bodyBox.y, this.bodyBox.w, this.bodyBox.h);
    }
    /// <summary>
    /// Renders the joint data to the Canvas by drawing ellipses and
    /// trying to avoid re-creating every ellipse every time although
    /// very questionable as to whether that's better/worse than
    /// showing/hiding them as I haven't tested.
    /// </summary>
    internal void RenderJointData()
    {
      foreach (var ellipse in this.jointEllipses.Values)
      {
        ellipse.Visibility = Visibility.Hidden;
      }
      if (this.currentJoints != null)
      {
        // We shoot for the joints where there is at least some confidence.
        var confidentJoints = this.currentJoints.Where(c => c.confidenceImage > 0).ToList();

        foreach (var joint in confidentJoints)
        {
          if (!this.jointEllipses.ContainsKey(joint.jointType))
          {
            this.jointEllipses[joint.jointType] = MakeEllipse();
          }
          var ellipse = this.jointEllipses[joint.jointType];

          ellipse.Visibility = Visibility.Visible;

          this.PositionCanvasShapeTopLeftAt(
            ellipse,
            (int)joint.image.x,
            (int)joint.image.y);
        }
      }
    }
    /// <summary>
    /// Updates the writeable bitmap with the latest frame captured.
    /// </summary>
    /// <param name="colorFrameBitmap"></param>
    internal void RenderBitmap(WriteableBitmap colorFrameBitmap)
    {
      colorFrameBitmap.WritePixels(
        this.colorFrameDimensions,
        this.colorFrameBuffer,
        this.colorFrameDimensions.Width * 4,
        0);
    }
    internal WriteableBitmap CreateBitmap()
    {
      return (new WriteableBitmap(
        this.colorFrameDimensions.Width,
        this.colorFrameDimensions.Height,
        96,
        96,
        PixelFormats.Bgra32,
        null));
    }
    void PositionCanvasShapeTopLeftAt(
      Shape shape,
      int x,
      int y)
    {
      Canvas.SetLeft(
        shape,
        this.ScaleXCameraValue(x, this.canvas.ActualWidth) - (shape.Width / 2));

      Canvas.SetTop(
        shape,
        this.ScaleYCameraValue(y, this.canvas.ActualHeight) - (shape.Height / 2));
    }
    void PositionCanvasShapeForBoundingBox(
      Shape shape,
      int x,
      int y,
      int width,
      int height)
    {
      if (width == 0)
      {
        shape.Visibility = Visibility.Hidden;
      }
      else
      {
        shape.Visibility = Visibility.Visible;

        shape.Width = this.ScaleXCameraValue(width, this.canvas.ActualWidth);

        shape.Height = this.ScaleYCameraValue(height, this.canvas.ActualHeight);

        Canvas.SetLeft(
          shape,
          this.ScaleXCameraValue(x, this.canvas.ActualWidth));

        Canvas.SetTop(
          shape,
          this.ScaleYCameraValue(y, this.canvas.ActualHeight));
      }
    }
    double ScaleXCameraValue(double value, double maximumValue)
    {
      return (value * this.xScaleMultiplierCameraToCanvas * maximumValue);
    }
    double ScaleYCameraValue(double value, double maximumValue)
    {
      return (value * this.yScaleMultiplierCameraToCanvas * maximumValue);
    }
    Ellipse MakeEllipse()
    {
      var ellipse = new Ellipse()
      {
        Fill = whiteBrush,
        Width = ELLIPSE_DIAMETER,
        Height = ELLIPSE_DIAMETER
      };
      this.canvas.Children.Add(ellipse);
      return (ellipse);
    }
    Rectangle MakeRectangle(Color rectangleColor)
    {
      var rectangle = new Rectangle()
      {
        Stroke = new SolidColorBrush(rectangleColor),
        StrokeThickness = 2
      };
      this.canvas.Children.Add(rectangle);
      return (rectangle);
    }
    SolidColorBrush whiteBrush;
    Dictionary<JointType, Ellipse> jointEllipses;
    PXCMPersonTrackingData.PersonJoints.SkeletonPoint[] currentJoints;
    double xScaleMultiplierCameraToCanvas;
    double yScaleMultiplierCameraToCanvas;
    PXCMRectI32 headBox;
    PXCMRectI32 bodyBox;
    Int32Rect colorFrameDimensions;
    byte[] colorFrameBuffer;
    int busyFlag;
    Canvas canvas;
    Rectangle headRectangle;
    Rectangle bodyRectangle;
    const int ELLIPSE_DIAMETER = 20;
  }
}

    [DllImport(DLLNAME)]
    [return: MarshalAs(UnmanagedType.Bool)]
    internal static extern Boolean PXCMPersonTrackingData_PersonJoints_QueryJoints(IntPtr instance, IntPtr joints);

    internal static Boolean QueryJointsINT(IntPtr instance, out SkeletonPoint[] joints)
    {
      int njoints = PXCMPersonTrackingData_PersonJoints_QueryNumJoints(instance);

      IntPtr joints2 = Marshal.AllocHGlobal(Marshal.SizeOf(typeof(SkeletonPoint)) * njoints);

      Boolean sts = PXCMPersonTrackingData_PersonJoints_QueryJoints(instance, joints2);

      if (sts)
      {
        joints = new SkeletonPoint[njoints];

        for (int i = 0, j = 0; i < njoints; i++, j += Marshal.SizeOf(typeof(SkeletonPoint)))
        {
          joints[i] = new SkeletonPoint();
          Marshal.PtrToStructure(new IntPtr(joints2.ToInt64() + j), joints[i]);
        }
      }
      else
      {
        joints = null;
      }
      Marshal.FreeHGlobal(joints2);
      return sts;
    }

  [Serializable]
        [StructLayout(LayoutKind.Sequential)]
        public class SkeletonPoint
        {
            public JointType jointType;
            public Int32 confidenceImage;
            public Int32 confidenceWorld;
            public PXCMPoint3DF32 world;
            public PXCMPointF32 image;
            public Int32[] reserved;

            public SkeletonPoint()
            {
                reserved = new Int32[10];
            }
        };

struct SkeletonPoint
		{
			JointType jointType;
			pxcI32 confidenceImage;
			pxcI32 confidenceWorld;
			PXCPoint3DF32 world;
			PXCPointF32   image;
			pxcI32 reserved[10];
		};

            [MarshalAs(UnmanagedType.ByValArray, SizeConst = 10)]
            public Int32[] reserved;

public Boolean QueryJoints(SkeletonPoint[] joints)
			{
				return QueryJointsINT(instance, out joints);
			}

public Boolean QueryJoints(out SkeletonPoint[] joints)
			{
				return QueryJointsINT(instance, out joints);
			}
